Metal ceilings and tiles - Directa
DIRECTA
Metal slatted ceiling with moldings
Stylish metal ceiling, which allows you to create a ceiling in various design-interesting variants.
The unusual appearance of the ceiling is given by the central recesses of the moldings.
Properties
-
All-metal construction
-
Surface treatment without perforation smooth, color PES white, standard white RAL 9010, other shades on request.
-
The DIRECTA ceiling is manufactured in accordance with the ČSN EN 13964 standard
-
Measurement of sound absorption performed by the Center of Civil Engineering as, according to ČSN EN ISO 354 and ČSN EN ISO 11654,
using sound-absorbing acoustic insulation -
DIRECTA slats are made of pre-painted sheet metal of reaction to fire class A2-s1, d0
Areas of application
To the interior as a design element
Suitable for ceilings and wall cladding
Quick aesthetic covering of the space above the ceiling
Quick aesthetic covering of air conditioning
To the atriums, offices, hotels, restaurants, corridors, entrances and halls
DIRECTA - specifications
Material:
Bar width:
Bar height:
Bar length:
Perimeter rail:
Plastic plug:
Hinge types:
Anchoring of end elements:
Isolation:
galvanized. steel - 0.4 and 0.5 mm, stainless steel. steel - 0.5 mm support rail - galvanized. steel 0.6 mm
33.2 mm
40 mm
standard 4000 mm, according to the customer's wishes 600–7000 mm
according to requirements, not supplied as standard
according to requirements, not supplied as standard
standard: wire with hook + double spring + wire with eye,
or threaded rods with a minimum diameter of 6 mm, or vernier
loading of the ceiling with other devices is not allowed,
the end elements must be hung separately
without acoustic insulation / with acoustic insulation
SELECTED REFERENCES
TELEHOUSE – administrative center
Kovový podhled DIRECTA
Kovový podhled DIRECTA
Kovový podhled DIRECTA
Kovový podhled DIRECTA
Production and installation of the DIRECTA slatted ceiling. According to the architects design, the problem of different height levels of the ceiling was solved by installing sloping triangular trasitions from the DIRECTA slats.
DBK shopping center Budějovická, Prague
Kovové mřížkové kazety
Kovové mřížkové kazety
Kovový podhled DIRECTA
Kovové mřížkové kazety
Production and delivery of metal grille cassettes and the DIRECTA metal slatted ceiling. The slats are finished in ALLEGRO WHITE color.
PPF-GATE
Kovový podhled DIRECTA
Kovový podhled DIRECTA
Kovový podhled DIRECTA
Kovový podhled DIRECTA
Delivery and installation of the DIRECTA skirted ceiling in different color variations: according to RAL: shiny stainless-steel, bleached oak and teak.
